DYS SunFun 2207.

Prisvärd motor från välkända DYS.

Data:
KV: 2550
Storlek motor: 27.7x18.7 mm
Vikt: 35.4 g
Spänning: 3-6S LiPo.
Watt: > 664 W (5S/6040-2)

DYS SunFun 2306.

Prisvärd motor från välkända DYS.

Data:
KV: 2500
Storlek motor: 28.5x17 mm
Vikt: 34.5 g
Spänning: 3-6S LiPo.
Watt: >700 W (5S)

ARIA 70 A BLHeli_32

Spec:
Inspänning: 3-6S LiPo
BEC: Nej
Storlek: 21 x 42  mm.
Vikt: 9.5 g.
Konstant belastning: 70 A (Burst 80 A).
Firmware: BLHeli_32

ARIA 45 A BLHeli_32

Spec:
Inspänning: 3-6S LiPo
BEC: Nej
Storlek: 34.5 x 11.5 x 5 mm.
Vikt: 3.5 g.
Konstant belastning: 40 A (Burst 50 A).
Firmware: BLHeli_32



Shark_Mako RTF från DYS.

Inkl. Sändare/mottagare, VTX o kamera, batteri och laddare.

Se Video!!  (flygning ca 8:20 in i videon).

Spec:
Storlek: 100 mm.
Vikt utan batteri: 93 g.
Flight controller: F4. (med BetaFlight).
Motor: BE1104-5400KV.
ESC: 4in1 F18A.
Propeller: 4-bladig 2035.
Lins: 150 grader (NTSC).
VTX: 5.8G, 40 kanaler, 25-200 mW.
Räckvidd VTX: ca. 500 m.
VTX antenn: 3 dBi.
Batteri: 600 mAh 3S (11.1 V).
Batteristorlek: 55x27x18 mm.
Flygtid: ca 5 min.
Sändare: D8, 2.4 GHz. (Kör OpenTX/FrSky kompatibel). Inbyggt batteri.
Räckvidd sändare: ca. 500 m.
Laddare för Sändare och LiPo drivacc medföljer!
Övrigt: Extra propellersats medföljer.

DYS Aria 45A ESC 4 in 1.

Spänning: 3-5S LiPo.
BEC: 5 V/3 A och 9 V/1.5 A.
Storlek: 43x40x8 mm.
Vikt: 19.8 g.
Ström: 45 A kontinuerligt. Burst: <10 sek. 50 A.

Features:
With 32bit ARM Cortex MCU STM32F051 48MHZ micro processor, throttle 2048 resolution ratio,strong anti-interference capacity.
Built-in two BEC 9V / 1.5A and 5V/ 3A.
The telemetry port and on-board current meter of the ESC can use the flat cable and it will test the current,voltage and power etc.
Built-in temperature sensor will pass the telemetry port to transfer and overlay to the OSD of FC,It can be programmed setting for temperature protection.
With USB linker can be programmable throttle setting like support positive and negative,two-way mode,FPV 3D mode,motor speed,braking ,PWM frequency, inlet angle speed setting, onboard RGB LED for customize color, Beep etc.
It use the self-adaption control system,can go automatic with the all kind of the motor in the market,at the mean time it support up to 500HZ PWM,oneshot 125,oneshot 42,Multishot and Dshot 150/300/600/1200.
With special optimize in multi-axis,the motor can launch smoother in a good throttle curve, fast response,great power, and highly support the multi-axis,fixed-wing and helicopter.
Signal wire is the silicone flat cable,it can connect with the DYS F4 FC directly,no need soldering.When it connect with the other brand FC,it will need to solder to the FC.
MCU hardware,Driver circuit ,Mosfet will come with double voltage protection.
To adopt the new process MOSFET of low internal resistance, will help increase resistance to flow.Also,the professional MOS driver chip makes the best efficiency.
Mosfet is covered with aluminum sheet for cooling,which can bring more efficiency and stability.
With special process of 8 layer thicken PCB will lower resistance, small calorific value and bigger impact resistance current.Nice optimize layout of the components and parts makes a smaller size,lighter weight and easy to build.

F4 PRO V2 från DYS.

DYS F4 PRO V2 flight control with high performance which is designed for FPV hobbyists. Not only combine PDB board together with flight control, but also integrated OSD, current meter, voltmeter and built-in high power BEC etc functions.

DYS F4 PRO V2 flight control can meet all the functions you need include FPV racer, aerobatic flight and aerial photograph.

Specification:
Betaflight “DYS F4 PRO” firmware
STM32F405 master with higher refresh rate and more function ports
5V 3A BEC output
9V 1.2A BEC output
3.3V 0.3A BEC output
Compatible all split-type escs, connect with DYS 4-in-1 esc (F20A or F30A) with flexible flat cable
Support BF setting software to flash and debug OSD
Integrated current sensor to monitor the power consumption etc in real time
Use remote control to view flight control parameter through OSD
Support SAMRT AUDIO, adjust the VTX by OSD
Comes with heat resistance damping ball to upgrade the stability and operation
3-6s lipo input, integrated PDB, max withstand current 160A
Net weight 10.5g, exclude the cable
The refresh rate of PID and gyro up to 8K

Data:
Whole size: L 38mmX W 38mm, hole distance 30.5X30.5mm
Six-layer PCB board and 3OZ copper to enhance the over-current and heat dissipation
PDB board with reverse high voltage protection circuit
MCU: STM32F405 GRT6
IMU: MPU-6000
OSD: AT7456E
FLASH:  8M memory
Current sensor: 0-200A
Added S5,S6 motor control signal (support 6 axis feature once firmware upgraded)
Integrated reverse high voltage protection circuit
Integrated circuit protection to USB port
3.3V LDO to power on internal circuit
9V BEC: 1.2A
5V BEC: 3A/ one-way output to avoid external interference
When use with 4-in-1 esc, plug in the battery to supply the flight control instead of BEC.

DYS Shu 2306.

Prisvärd motor från välkända DYS.

Data:
KV: 2800
Storlek stator: 23x6 mm.
Storlek motor: 28.5x17 mm
Vikt: 33.6 g
Spänning: 3-4S LiPo.
Max kontinuerlig ström: 42 A.
Max effekt: 672 W

DYS Shu 2306.

Prisvärd motor från välkända DYS.

Data:
KV: 2500
Storlek stator: 23x6 mm.
Storlek motor: 28.5x17 mm
Vikt: 33.6 g
Spänning: 3-4S LiPo.
Max kontinuerlig ström: 44.1 A.
Max effekt: 705.6 W

DYS Wei 2207.

Prisvärd motor från välkända DYS.

Data:
KV: 2600
Storlek stator: 22x7 mm.
Storlek motor: 27.7x18.2 mm
Vikt: 34.7 g
Spänning: 3-4S LiPo.
Max kontinuerlig ström: 44 A.
Max effekt: 704 W

DYS Wei 2207.

Prisvärd motor från välkända DYS.

Data:
KV: 2300
Storlek stator: 22x7 mm.
Storlek motor: 27.7x18.2 mm
Vikt: 36.2 g
Spänning: 3-4S LiPo.
Max kontinuerlig ström: 36.2 A.
Max effekt: 579.2 W

DYS Wu 2206.

Prisvärd motor från välkända DYS.

Data:
KV: 2700
Storlek stator: 22x6 mm.
Storlek motor: 27.7x18.7 mm
Vikt: 31.15 g
Spänning: 3-4S LiPo.
Max kontinuerlig ström: 43.2 A.
Max effekt: 691.2 W

DYS Wu 2206.

Prisvärd motor från välkända DYS.

Data:
KV: 2400
Storlek stator: 22x6 mm.
Storlek motor: 27.7x18.7 mm
Vikt: 31.15 g
Spänning: 3-4S LiPo.
Max kontinuerlig ström: 32.7 A.
Max effekt: 523.2 W

DYS Mini Baby FC f4 and F18A ESC 4in1.

Specs
* STM32F405 master with higher refresh rate and more function ports
* Six-layer PCB board and 3OZ copper to enhance the over-current and heat dissipation
* Six axis senor MPU600 connects by SPI
* Compatible all split-type escs
* Microcontroller controls OSD chip through SPI bus DMS mode and faster speed
* Support BF setting software to flash and debug OSD
* 5V power supply max up to 2A
* Use remote control to view flight control parameter through OSD
* Support SAMRT AUDIO, IRC TARAMP agreement, adjust the VTX frequency and power etc by flight control (will support DYS new VTX)
* Comes with heat resistance damping ball to upgrade the stability and operation
* 2-4s lipo input support, with the anti-ignition function TVS device
* Net weight 6g without cable
* Dimension L 30mmX W 27mm, hole distance 20X20mm

Mini 4-in-1 F18A esc
Features:
- Continue Current: 18A, Burst Current: 22A up to 10S
- Input Voltage: 2-4S Lipo
- BEC Output: 5V/ 2A
- Size: 33*30*7.5mm
- Weight: 6g(exclude cable and connector)
- Firmware: BLHeli_S
- Mounting hole size: 20x20mm
- Support Dshot150/300/600, Oneshot125/42, Multishot, PWM

Model: BN6045

Antal proppar: 4 st, 2 st CW + 2 st CCW.

Hi-Performance Prop 6045 FPV bullnose propeller CW/CCW
Material: PC
Size: 6 x 4.5
Hub inner diameter(ID): M5
Hub thickness: 7mm
Weight: 5.39g/pc
Application: 250, 280. 300 frame etc

Model: BN6045

Antal proppar: 4 st, 2 st CW + 2 st CCW.

Hi-Performance Prop 6045 FPV bullnose propeller CW/CCW
Material: PC
Size: 6 x 4.5
Hub inner diameter(ID): M5
Hub thickness: 7mm
Weight: 5.39g/pc
Application: 250, 280. 300 frame etc

Model: BN6045

Antal proppar: 4 st, 2 st CW + 2 st CCW.

Hi-Performance Prop 6045 FPV bullnose propeller CW/CCW
Material: PC
Size: 6 x 4.5
Hub inner diameter(ID): M5
Hub thickness: 7mm
Weight: 5.39g/pc
Application: 250, 280. 300 frame etc

Model: BN6045

Antal proppar: 4 st, 2 st CW + 2 st CCW.

Hi-Performance Prop 6045 FPV bullnose propeller CW/CCW
Material: PC
Size: 6 x 4.5
Hub inner diameter(ID): M5
Hub thickness: 7mm
Weight: 5.39g/pc
Application: 250, 280. 300 frame etc

Model: BN6045

Antal proppar: 4 st, 2 st CW + 2 st CCW.

Hi-Performance Prop 6045 FPV bullnose propeller CW/CCW
Material: PC
Size: 6 x 4.5
Hub inner diameter(ID): M5
Hub thickness: 7mm
Weight: 5.39g/pc
Application: 250, 280. 300 frame etc

Model: BN6045

Antal proppar: 4 st, 2 st CW + 2 st CCW.

Hi-Performance Prop 6045 FPV bullnose propeller CW/CCW
Material: PC
Size: 6 x 4.5
Hub inner diameter(ID): M5
Hub thickness: 7mm
Weight: 5.39g/pc
Application: 250, 280. 300 frame etc

ARIA 35A BLHeli_32  DShot

Weight: 4.37g(exclude the wire)

Input voltage: 3-6s Lipo

Size(mm)L*W: 32*16*5

Firmware : BLHeli_32

Features:

With 32 bit ARM Cortex MCU STM32F051 48MHZ micro processor, throttle 2048 resolution ratio,strong anti-interference capacity.

Built-in sensor can be reaction of temperature,output power,output current etc,also programmable for protection.

Support Blheli_32 firmware,can use the signal wire to upgrade the firmware or change the configuration on line.

Current Meter to help show current indication of OSD

With USB linker can be programmable throttle setting like support positive and negative,two way mode,FPV 3D mode,motor speed,braking ,PWM frequency, inlet angle speed setting, onboard RGB LED for customize color, Beep etc.

It use the self-adaption control system,can go automatic with the all kind of the motor in the market,at the mean time it support up to 500HZ PWM,oneshot 125,oneshot 42,Multishot and Dshot 150/300/600/1200.

With special optimize in multi-axis,the motor can launch smoother in a good throttle curve, fast response,great power, and highly support the multi-axis,fixed-wing and helicopter.

The twisted-pair signal wire can lower the crosstalk inside cooper wire when it transfer,which will make the flight more stable.

MCU hardware,Driver circuit ,Mosfet will come with double voltage protection.

To adopt the new process MOSFET of low internal resistance, will help increase resistance to flow. Also,the professional MOS driver chip makes the best efficiency.

Mosfet is covered with aluminum sheet for cooling,which can bring more efficiency and stability.

With special process of 6 layer thicken PCB will lower resistance, small calorific value and bigger impact resistance current.Nice optimize layout of the components and parts makes a smaller size,lighter weight and easy to build.

FPV Racing Strap by DYS.

Model: XT50403

Hi-Performance Prop FPV 3 blade bullnose propeller 5040 CW/CCW

Material: PC

Size: 5 x 4

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 3.2g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50403

Hi-Performance Prop FPV 3 blade bullnose propeller 5040 CW/CCW

Material: PC

Size: 5 x 4

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 3.2g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50403

Hi-Performance Prop FPV 3 blade bullnose propeller 5040 CW/CCW

Material: PC

Size: 5 x 4

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 3.2g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50403

Hi-Performance Prop FPV 3 blade bullnose propeller 5040 CW/CCW

Material: PC

Size: 5 x 4

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 3.2g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50403

Hi-Performance Prop FPV 3 blade bullnose propeller 5040 CW/CCW

Material: PC

Size: 5 x 4

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 3.2g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50403

Hi-Performance Prop FPV 3 blade bullnose propeller 5040 CW/CCW

Material: PC

Size: 5 x 4

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 3.2g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50404

Hi-Performance Prop FPV 4 blade bullnose propeller 5040 CW/CCW

Material: PC

Size: 5 x 4

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 4.8g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50404

Hi-Performance Prop FPV 4 blade bullnose propeller 5040 CW/CCW

Material: PC

Size: 5 x 4

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 4.8g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50404

Hi-Performance Prop FPV 4 blade bullnose propeller 5040 CW/CCW

Material: PC

Size: 5 x 4

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 4.8g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50404

Hi-Performance Prop FPV 4 blade bullnose propeller 5040 CW/CCW

Material: PC

Size: 5 x 4

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 4.8g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50404

Hi-Performance Prop FPV 4 blade bullnose propeller 5040 CW/CCW

Material: PC

Size: 5 x 4

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 4.8g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50404

Hi-Performance Prop FPV 4 blade bullnose propeller 5040 CW/CCW

Material: PC

Size: 5 x 4

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 4.8g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: X40453

Hi-Performance Prop FPV 3 blade bullnose propeller 4045 CW/CCW

Material: PC

Size: 4 x 4.5

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 3.82g

Application: 130.160.180 frame etc

Model: X40453

Hi-Performance Prop FPV 3 blade bullnose propeller 4045 CW/CCW

Material: PC

Size: 4 x 4.5

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 3.82g

Application: 130.160.180 frame etc

Model: X40453

Hi-Performance Prop FPV 3 blade bullnose propeller 4045 CW/CCW

Material: PC

Size: 4 x 4.5

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 3.82g

Application: 130.160.180 frame etc

Model: XT50513

Antal: 1 par (CW+CCW)

Hi-Performance Prop FPV 3 blade propeller 5051 CW/CCW

Material: PC

Size: 5 x 5.1

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 5.65g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50513

Antal: 1 par (CW+CCW)

Hi-Performance Prop FPV 3 blade propeller 5051 CW/CCW

Material: PC

Size: 5 x 5.1

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 5.65g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50513

Antal: 1 par (CW+CCW)

Hi-Performance Prop FPV 3 blade propeller 5051 CW/CCW

Material: PC

Size: 5 x 5.1

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 5.65g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50513

Antal: 1 par (CW+CCW)

Hi-Performance Prop FPV 3 blade propeller 5051 CW/CCW

Material: PC

Size: 5 x 5.1

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 5.65g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50433

Antal: 1 par (CW+CCW)

Hi-Performance Prop FPV 3 blades propeller 5043 CW/CCW

Material: PC

Size: 5 x 4.3

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 9.91g (cw/ccw Pair)

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50433

Antal: 1 par (CW+CCW)

Hi-Performance Prop FPV 3 blades propeller 5043 CW/CCW

Material: PC

Size: 5 x 4.3

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 9.91g (cw/ccw Pair)

Application: 200, 210, 230, 250, 280, 320 frame etc

New design with imported NMB bearing
N52 magnet and 0.2mm lamination
Powerful with 450g thrust to work with 4" Prop
Special design for the FPV racer champions

Data:
Modell: SE1407II
Kv: 3600
Volt: 11.1 - 14.8 V (3 - 4S LiPo).
Max dragkraft: 450 g (4S/14.6 A).
Max effekt: 256 W
Max Continuous current: 17.3 A
Fartreglage: 20 A.
Diam: 18.3 mm.
Längd: 16 mm (exkl. axel).
Statordiam.: 14 mm.
Axeldiam: 3 mm
Vikt: 14 g.
Adapter medföljer.
Propp: Se tabell.


Racing Proppar

20A 4-in-1 F20A esc

Features:

- Continue Current: 20A, Burst Current: 25A up to 10S

- Input Voltage: 2-4S Lipo

-  BEC Output: 5V/12  3A

- Size: 36*36*8mm

- Weight: 21g(include cable and connector)

- Firmware: BLHeli_S

- Support Dshot150/300/600, Oneshot125/42, Multishot, PWM

- Main IC: EMF8BB21F16G SILABS, 8bit C8051, run 50MHz

Model: XT50513

Antal: 1 par (CW+CCW)

Hi-Performance Prop FPV 3 blade propeller 5051 CW/CCW

Material: PC

Size: 5 x 5.1

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 5.65g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50513

Antal: 1 par (CW+CCW)

Hi-Performance Prop FPV 3 blade propeller 5051 CW/CCW

Material: PC

Size: 5 x 5.1

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 5.65g

Application: 200, 210, 230, 250, 280, 320 frame etc

Model: XT50433

Antal: 1 par (CW+CCW)

Hi-Performance Prop FPV 3 blades propeller 5043 CW/CCW

Material: PC

Size: 5 x 4.3

Hub inner diameter(ID): M5

Hub thickness: 7mm

Weight: 9.91g (cw/ccw Pair)

Application: 200, 210, 230, 250, 280, 320 frame etc

XSD30A V2 Solder Version

Ersätts av Aria 35A.

Input voltage: 3-5S LiPo
BEC: Nej
Type: BLheli_S Firmware & DShot600/ DShot300
Weight: 7.2 g
Size: 30x15x6 mm
Feature: Silabs EFM8BB21

BLHeli_S ESC with Hardware generated PWM synchronous to MCU yields ultra-quiet motor performance.
Utilizes high-performance EFM8BB21 50MHz MCU
BLHeli_S does Damped Light only

Firmware upgradable via signal wire (works with USB Linker for XM series)

Supports Motors with super high KV (EFM8BusyBee 50MHz can handle up to 500k eRPM)
High-current burst rating
High-Resolution Throttle steps

BLHeli_S ESC with Hardware generated PWM synchronous to MCU yields ultra-quiet motor performance.

Utilizes high-performance EFM8BB21 50MHz MCU
BLHeli_S does Damped Light only
Firmware upgradable via signal wire (works with USB Linker for XM series)
Supports Motors with super high KV (EFM8BusyBee 50MHz can handle up to 500k eRPM)
Supports DShot600, DShot300.
High-current burst rating
High-Resolution Throttle steps

Specifications:

DYS XS Series XSD20A 3-4S Speed Control (BLHeli_S Firmware, support Dshot600, Dshot300)
Item Name: XSD20A solder version
Input voltage: 3-4s Lipo
BEC: NO
Size(mm)L*W*H: 24*14*4.5mm
Type: BLheli_S & Dshot600/Dshot300
Weight: 4.32g
Feature: Silabs EFM8BB21

DYS V2 USB Linker for DYS XM Series ESCs

Item Name: DYS USB Linker V2
Size (L*W*H): 54*22*9 (mm)
Weight: 8g
Applicable: all DYS XM series

The mini USB Linker for the ESC programmer to flash BLHeli bootloader.
